Brake Rotor - 4 Bolt 182mm 85mm Brake Disc, 400-800cc, Hisun

Brake Rotor - 4 Bolt 182mm 85mm Brake Disc, 400-800cc, Hisun

Product Number:
90A2083
Availability:
In Stock
Price:
$69.99 CAD


  Description

Left rear disc brake rotor. Made from hardened, corrosion resistant steel. Commonly used for (but not limited to) 800cc engines, such as the Hisun 800cc UTVs, as well as many other clones, rebrands and similar displacement machines.

These machines are commonly manufactured by Chongqing Huansong Industries (Group) Co., Ltd. and distributed by a range of exporters, importers and distributors under such brands as: Hisun, Bennche, Coleman, Massimo, Qlink, Menards Yardsport, Big Muddy, Powermax, Nordik, TSC, Rural King, Cub Cadet, Excalibur, US Titan / Supermach, Precision, JMC and many others.

Common Hisun model names are primarily listed as variations of "Hisun 800cc UTV", "Hisun HS800UTV" and "HSUN HS800 E-mark EFI". Common listed Hisun brake rotor part number is 41205-115-0000 and ERP part number is 41205-115-0000. Also applies to some other variations of Hisun models.

Common Nordik model names are primarily listed "Nordik NK 800 U (NK800U)". Common listed Nordik brake rotor part number is 41205-115-0000 and ERP part number is 41205-115-0000. Also applies to some other variations of Nordik models.

Common Powermax model names are primarily listed as "Powermax Roughrider 800 UTV". Common listed Powermax brake rotor part number is 41205-115-0000 and ERP part number is 41205-115-0000. Also applies to some other variations of Powermax models.

  • Manufacturer PN: 41205-115-0000
Approximate dimensions:
  • Outer Diameter: 182mm
  • Centre Hole: 85mm
  • Thickness: 3.5mm
  • Mounting Holes: 10.4mm
  • Mounting Hole Spacing (across): 101mm (centre to centre)
  • Mounting Hole Spacing (side by side): 72mm (centre to centre)
